Fiber Optic Test Meter CCT-503

Description:
CCT-503 Visual Fault Locator uses 650nm laser module as emitter. The output mode can be chosen between CW and 2Hz frequency of light, it is widely used in optical communication, optical components measurement, fiber optical sensor and other fields.

Features:
1.Optional auto-shutdown
2.Large LCD display and optional backlight
3.Battery power display

Application:
1.Maintenance Telecom
2.Maintenance CATV
3.Test Lab of Fiber Optic
4.Optical fiber sensors

Specifications:

• Emitter Type FP-LD
• Wavelength（nm） 650
• Optical Connector FC/SC/ST
• Ouput Power(mw) ≥ 10
• Modulation Frequencies CW、2Hz
